Product Details:
|
| Capacity: | 450kg 630kg 800kg 1000kg 1250kg 1600kg 2000kg 2500kg | Speed: | 1.0m/s 1.5m/s 1.75m/s 2.0m/s 2.5m/s |
|---|---|---|---|
| Drive: | Traction VVVF | Machine Room: | Without Machine Room |
| Machine: | Permanent Magnet Sychronous Gearless Traction Machine | Door Protection: | Full Range Of Infrared Light Curtain Protection |
| Decoration: | Glass Cabin Wall Glass Doors | Display Of COP And HOP: | Dotmatrix LCD |
| Door Opening: | Center Opening Side Opening Telescopic Opening | HS Code: | 8428101090 |
| Highlight: | TISCHBEIN Sightseeing Elevator 360° Glass Wall,TISCHBEIN Panoramic Elevator 800kg Rated Load,TISCHBEIN 1000kg Glass Lift Low Power Consumption |
||
2.0m/s traction panoramic elevator sightseeing elevator Observation elevator Glass elevator with gearless motor for Hotel Shopping Mall Residential Building
The fresh new panoramic elevator is of the elegant and beautiful outline model, the extraordinarily distinguished grade. It helps you to appreciate the outstanding charm and luxurious manner of modern architectures. It complies with the energy-saving VVVF variable frequency drive and quietly bears the fully deducts the profound knowledge of TISCHBEIN elevator to modern urban life by the steady and comfortable travel experience, the unique style of popular outlook, the humane interface setting.
1. Specification
| TISCHBEIN Machine Roomless Panoramic Elevator | ||||||||
| Loading ( Kgs) |
Person | Speed ( m/s) |
Roping | Shaft Clear Inner Size ( W*D in mm) |
Car Clear Inner Size ( W*D*H in mm) |
Door Open ( W*H in mm) |
Pit Depth ( mm) |
Overhead Heigh |
| 450 | 6 | 1.00 | 2:1 | 1800W*1700D | 1000W*1200D*2250H | 800W*2100H | ≥1500 | ≥4400 |
| 1.50 | ≥1600 | ≥4600 | ||||||
| 1.75 | ≥1700 | ≥4700 | ||||||
| 630 | 8 | 1.00 | 2:1 | 2000W*1800D | 1100W*1400D*2250H | 800W*2100H | ≥1500 | ≥4400 |
| 1.50 | ≥1600 | ≥4600 | ||||||
| 1.75 | ≥1700 | ≥4700 | ||||||
| 800 | 10 | 1.00 | 2:1 | 2200W*1800D | 1350W*1400D*2250H | 800W*2100H | ≥1500 | ≥4400 |
| 1.50 | ≥1600 | ≥4600 | ||||||
| 1.75 | ≥1700 | ≥4700 | ||||||
| 1000 | 13 | 1.00 | 2:1 | 2250W*2000D | 1400W*1600D*2250H | 900W*2100H | ≥1500 | ≥4400 |
| 1.50 | ≥1600 | ≥4600 | ||||||
| 1.75 | ≥1700 | ≥4700 | ||||||
2. Elevator Parts Main Components
We adopt newest technology and high quality components
VVVF permanent magnet Door Operator System
Permanent magnet sychronous gearless Traction Machine
One-piece Control Cabinet
The light curtain door protection
LED lighting system
Triple guards intelligent automatic rescuing
TSO-10 series panoramic elevator of compact layout and optimized space,is not restricted by building structures, which is flexibly applied to various vertical passenger transportation scenarios.
Space improvement 50%
The machine room area overlaps with the hoistway area and the height is reduced,which can save 50%area of the original machine room.The overall compact structure can provide wider car space and make the elevator riding capacious and comfortable.
Excellent carrying performance
Equipped with permanent magnet synchro-nous gearless drive and computer intelligent control system,it operates stably and securely with low noise.
TISCHBEIN ELEVATOR, TIED TO SAFETY. And welcome to contact us!
